Edwards nXRi Multi-Stage Roots Vacuum Pumps

Representative Image

Edwards nXRi Multi-Stage Roots Vacuum Pumps 1

Edwards nXRi Multi-Stage Roots Vacuum Pumps 2

Edwards nXRi Multi-Stage Roots Vacuum Pumps 3

Edwards nXRi Multi-Stage Roots Vacuum Pumps 4

Edwards nXRi Multi-Stage Roots Vacuum Pumps

The nXRi high performance, compact dry pump delivers unrivaled pumping speeds in the most compact package, with easy integration into new or existing vacuum systems. The nXRi's lower input power and zero maintenance create real performance improvements and cost benefits across a range of applications.

Dimensional Drawings

Edwards nXRi Multi-Stage Roots Vacuum Pumpsdrawing

Charts

Edwards nXRi Multi-Stage Roots Vacuum Pumpschart

Videos

Edwards Presents nXRi High Performance Compact Dry Vacuum Pump

Edwards has revolutionised the vacuum pump market with the new nXRi high performance, compact dry pump. It delivers unrivalled pumping speeds in the most compact package.

Runtime: 2:29

Specifications Table

Pump Model	nXR30i	nXR40i	nXR60i	nXR90i	nXR120i
Pumping Speeds	50 (Hz) 18.0 CFM 30.0 m³/hr 60 (Hz) 18.0 CFM 30.0 m³/hr	50 (Hz) 24.0 CFM 40.0 m³/hr 60 (Hz) 24.0 CFM 40.0 m³/hr	50 (Hz) 35.3 CFM 60.0 m³/hr 60 (Hz) 35.3 CFM 60.0 m³/hr	50 (Hz) 53.0 CFM 90.0 m³/hr 60 (Hz) 53.0 CFM 90.0 m³/hr	50 (Hz) 71.0 CFM 120 m³/hr 60 (Hz) 71.0 CFM 120 m³/hr
Ultimate Pressure	Total Without Gas Ballast 3.00 x 10^-2 mbar 2.25 x 10^-2 Torr	Total Without Gas Ballast 3.00 x 10^-2 mbar 2.25 x 10^-2 Torr	Total Without Gas Ballast 3.00 x 10^-2 mbar 2.25 x 10^-2 Torr	Total Without Gas Ballast 3.00 x 10^-2 mbar 2.25 x 10^-2 Torr	Total Without Gas Ballast 3.00 x 10^-2 mbar 2.25 x 10^-2 Torr
Cooling Method(s)	Method Convection	Method Convection	Method Convection	Method Convection	Method Convection
Motor Power HP (kW)	1.34 ( 1.00 )	1.34 ( 1.00 )	1.34 ( 1.00 )	1.34 ( 1.00 )	1.34 ( 1.00 )
Inlet Flange	KF25	KF25	KF40	KF40	KF40
Exhaust Flange	KF25	KF25	KF25	KF25	KF25
Noise db(A)	55.0	55.0	55.0	55.0	55.0
Weight Lbs (kg)	60.0 ( 27.0 )	60.0 ( 27.0 )	64.0 ( 29.0 )	64.0 ( 29.0 )	64.0 ( 29.0 )
Dimensions in. (mm.) (W/D/H)	8.60 x 18.8 x 12.0 (217 x 478 x 301 )	8.60 x 19.5 x 12.0 (217 x 478 x 301 )	8.60 x 19.5 x 12.0 (217 x 494 x 301 )	8.60 x 19.5 x 12.0 (217 x 494 x 301 )	8.60 x 19.5 x 12.0 (217 x 494 x 301 )
Lubrication Type	Dry	Dry	Dry	Dry	Dry
Technology Type	Multi-Stage Roots	Multi-Stage Roots	Multi-Stage Roots	Multi-Stage Roots	Multi-Stage Roots

X CLOSE

Ordering Table

X CLOSE

Pump Model	Inlet Flange	Voltage & Phases	Manual	Description	Part Number	Price	In Stock	Add To Cart	Accessories
Pump Model	Inlet Flange	Voltage & Phases	Manual	Description	Part Number	Price	In Stock	Add To Cart	Accessories
nXR30i	KF25	100-127/200-240V 50/60 Hz, 1- Ø		Edwards Vacuum nXR30i Multi-Stage Roots Pump, KF25 Inlet Flange, 30 m^3/hr at 50Hz / 18 CFM at 60Hz, Convection Cooling, 100-127 VAC/200-240 VAC 50/60 Hz, 1- Ø, Mains Cable Not Included	A90301983	P.O.R.
nXR40i	KF25	100-127/200-240V 50/60 Hz, 1- Ø		Edwards Vacuum nXR40i Multi-Stage Roots Pump, KF25 Inlet Flange, 40 m^3/hr at 50Hz / 24 CFM at 60Hz, Convection Cooling, 100-127 VAC/200-240 VAC 50/60 Hz, 1- Ø, Mains Cable Not Included	A90401983	$19,744.00
nXR60i	KF40	100-127/200-240V 50/60 Hz, 1- Ø		Edwards Vacuum nXR60i Multi-Stage Roots Pump, KF40 Inlet Flange, 60 m^3/hr at 50Hz / 35.3 CFM at 60Hz, Convection Cooling, 100-127 VAC/200-240 VAC 50/60 Hz, 1- Ø, Mains Cable Not Included	A90502983	P.O.R.
nXR90i	KF40	100-127/200-240V 50/60 Hz, 1- Ø		Edwards Vacuum nXR90i Multi-Stage Roots Pump, KF40 Inlet Flange, 90 m^3/hr at 50Hz / 53 CFM at 60Hz, Convection Cooling, 100-127 VAC/200-240 VAC 50/60 Hz, 1- Ø, Mains Cable Not Included	A90602983	$23,693.00
nXR120i	KF40	100-127/200-240V 50/60 Hz, 1- Ø		Edwards Vacuum nXR120i Multi-Stage Roots Pump, KF40 Inlet Flange, 120 m^3/hr at 50Hz / 71 CFM at 60Hz, Convection Cooling, 100-127 VAC/200-240 VAC 50/60 Hz, 1- Ø, Mains Cable Not Included	A90702983	P.O.R.
